Platen Punching Machine

Platen Punching Machine
Platen Punching Machine
Product Code : GNMC-01
Brand Name : GNMC
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Unit/Units
Product Description



We are engaged in manufacturing, supplying and exporting a qualitative range of Platen Punching Machine to our highly valued clients. It is mainly used to cut paper corrugated and solid fibre boxes, cartons, decals, gaskets, puzzle games, advertising displays, greeting cards & book covers. Plate Punching Machine can also cut different materials like fibreglass sheets, vinyl, foam, rubber, duplex board, polythene, plastic, felt, leather, etc. Clients can avail it from us at highly affordable prices in the market.


SILENT FEATURES:



  • Worm Gear impression adjustment mechanism.
  • Hardened and Ground Impression plate.
  • Automatic Lubrication System.
  • Trip bar on Moving Platen.
  • Variable Speed With inverter drive.
  • Double 'S' cam in large sizes.

Sizes and Technical Specifications



DP-29

DP-35

DP-40

DP-45

DP-54

DP-65

DP-76

Inside Chase

Size

(Inch)

20x26

22x32

25x37

32 1/2 42 1/2

36x51

42x62

52x72

(MM)

508x660

559x813

635x940

825x1079

914x1295

1067x1575

1320x1828

Moving Platen

Size

(Inch)

23x29

25x35

28x40

35 1/2 x 45 1/2

39 x 55 1/2

45x65

56x76

(MM)

584x736

635x889

711x1016

901x155

990x1410

1143x1651

1422x1930

Floor Space

(Inch)

52x68

61x70

707x72

72x80

78x90

83x99

90x115

(MM)

1320x1727

1549x1778

178x1828

1828x2032

1981x286

2108x2514

2286x2921

Impressions Per Hour


1600

1500

1400

1200

1100

1000

900

Power Required


3 H.P.

3 H.P.

5 H.P.

7.5 H.P.

7.5 H.P.

12.5 H.P.

15 H.P.

Weight (Appx.) (Kg)


2700

3450

4400

5600

7100

11000

14500


Trade Information
  • Payment Terms
  • Cheque, Others
  • Packaging Details
  • Wooden Packaging
  • Main Export Market(s)
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001:2015
